Corsair Twin2X2048-8500C5 2GB PC2-8500 Memory Kit Review
Corsair Twin2X2048-8500C5 2GB PC2-8500 Memory Kit Review - PCSTATS
Abstract: Just look at these specs - default timings are 5-5-5-15, each PC2-8500 module is 1024MB in size, and Corsair guarantees that its memory can run at a blistering 1066 MHz! Yikes!
 84% Rating:
Filed under: Memory Published:  Author:
External Mfg. Website: Corsair Jun 29 2006   C. Sun
Home > Reviews > Memory > Corsair Twin2X2048-8500C5

Max OC Chart and Conclusion

It's great to see how individual memory stacks up against the competition under stock configurations, but we're also going to show how it compares when overclocked. With performance in mind, we're going to compare the maximum overclocked results of the various DDR2 DIMMs we've tested in the past which are listed below. Remember, just because memory is clocked fast doesn't mean it's the best thing for a computer. Timings are also important, and getting the right ratio of both is the real key to performance based overclocking!

Maximum Overclocked Speeds - PCstats Results

Maximum Speed w/ Low Latency


Capacity Max Speed


Corsair Twin2X2048-6400C4 4-4-4-12 1024MB 1016 MHz
Corsair Twin2X2048-8500C5 4-4-4-12 1024MB 952 MHz
Corsair Twin2X2048-6400C3 3-4-3-9 1024MB 872 MHz
SyncMAX PC2-5300 Express 4-4-4-10 512MB 840 MHz
Crucial Ballistix PC2-5300 3-3-3-12 1024MB 790 MHz

Maximum Speed


Capacity Max Speed


Corsair Twin2X2048-6400C4 5-5-5-15 1024MB 1104 MHz
Corsair Twin2X2048-8500C5 5-5-5-15 1024MB 1104 MHz
Corsair Twin2X2048-6400C3 5-5-5-15 1024MB 1056 MHz
Crucial Ballistix PC2-5300 5-5-5-15 512MB 1056 MHz
SyncMAX PC2-5300 Express 5-5-5-15 1024MB 904 MHz

Even though the 2GB Corsair Twin2X2048-8500C5 kit is not intended to for use with tight timings (stock = 5-5-5-15), performance is still pretty good overall. It's a shame the Foxconn C51XEM2AA motherboard topped out so quickly, it's a definite that the Corsair Twin2X2048-8500C5 can overclock higher than 1104 MHz.

Does Corsair Redefine High Speed DDR-2?

It doesn't matter if you're a fan of DDR-2 memory or staunchly holding onto those trust DDR sticks, it's the memory standard that will be with us for the next few years and there is no changing that. Multi-core processors require more bandwidth than conventional memory standards provide, thus DDR2 is a necessity.

The debate between low latency and memory bandwidth has been raging almost since the dawn of computing, and the arguments are alive and well with DDR2. There is no best memory, it really depends on what you want to do with your computer.

With dual core processors like the Intel Pentium D, high speed DDR-2 memory allows you to overclock much higher without the fear of bandwidth starving the processor. With the Socket AM2 AMD Athlon64's wonky memory controller, high speed memory is also easier to overclock. However, an Athlon64 core is still an Athlon64 core, and it will always react positively to lower latency memory than naught.

Corsair's 2GB Twin2X2048-8500C5 DDR-2 memory kit is squarely designed for the enthusiast at heart. With the ability to run at 1066 MHz by default, the Twin2X2048-8500C5 memory is the definition of fast. To reach this speed though, Corsair recommends a voltage of 2.2V which is pretty high, better to have good case cooling 'cause this memory generates a fair amount of heat.

Even with the lax 5-5-5-15 timings the performance of the Corsair Twin2X2048-8500C5 at DDR2-800 speeds was decent, and it did not trail the low latency memory by much. The Twin2X2048-8500C5 memory was able to run at 276 MHz without any problems, yet I have the feeling it could have gone much higher if the nForce 590 based motherboard had not maxed out first.

When we consider the benchmark and bandwidth figures for the Corsair Twin2X2048-8500C5 memory running on a socket AM2 AMD Athlon64 FX-62 platform, at 276 MHz, it really underscores what good enthusiast grade memory is capable of. Low latency timings of 4-4-4-12 limited the memory to just 238 MHz however.

The Corsair Twin2X2048-8500C5 is highly specialized memory and if you're looking for something that can reach insane clock speeds, look no further. Hardcore overclocking is an expensive hobby and with a retail price of $510 CDN ($455 US, £246) for 2GB of DDR-2 it is priced at a premium, but it's about the best you can get.

PCSTATS Recommended Product Award

Find out about this and many other reviews by joining the Weekly PCstats.com Newsletter today! Catch all of PCSTATS latest reviews right here.
