Nero DiskSpeed 4: CD-R, CD-RW Media

Source: Ahead Software

Nero DiskSpeed 4's recordable CD media tests are done twice, once with a CD-R disc rated to 1x-52x burn speed, and again with a CD-RW rated to 4x-32x. This test is performed by simply placing blank recording media into the burner and running the benchmark. The software will detect if it is CD-R or CD-R/W media and run the appropriate tests.

CD-R

CD-RW

CD-R and CD-RW Media Benchmark Results
Optical Drive	Plextor PX-LB950UE		Lite-on iHAS524		Lite-on iHAS424
Media	CD-R	CD-RW	CD-R	CD-RW	CD-R	CD-RW
Media Write Speed:	48x	32x	48x	32x	48x	32x
Avg Speed:	37.07x	21.44x	36.78x	24.09x	36.77x	24.09x
Start Speed:	21.62x	16.02x	21.63x	16.06x	21.62x	16.05x
End Speed:	48.03x	24.05x	48.53x	32.18x	48.51x	32.18x
Type	CAV	Z-CLV	CAV	Z-CLV	CAV	Z-CLV

The Plextor PX-LB950UE achieves its listed CD-R read speed of 48x and CR-RW read speed of 24x

Nero DiskSpeed 4: DVD+RW Media

Source: Ahead Software

Nero's DiskSpeed 4 tests a DVD+RW rated to 2.4-4x. This test is done by simply placing the blank recording media into the burner and running the application. The software will detect the type of DVD media and run the appropriate test.

DVD+RW

DVD+RW Media Benchmark Results
Optical Drive	Plextor PX-LB950UE	Lite-On iHAS524	Lite-On iHAS424
Media	DVD+RW	DVD+RW	DVD+RW
Media Write Speed:	4x	4x	4x
Avg Speed:	9.17x	9x	9x
Start Speed:	5.09x	4.96x	4.97x
End Speed:	12.26x	12.04x	12.04x
Random Seek Time:	116ms	105 ms	109ms
Interface Burst Rate	32 MB/s	58 MB/s	59MB/s
Type	CAV	CAV	CAV

Plextor's PX-LB950UE maintains an average 9x read for DVD+RW media, slightly above the 8x rating.

Nero DiskSpeed 4: DVD-R Media

Source: Ahead Software

Nero's DiskSpeed 4 tests a DVD-R by simply placing the blank recording media into the burner and running the app. The software will detect the type of DVD media and run the appropriate test.

DVD-R

DVD-R Media Benchmark Results
Optical Drive	Plextor PX-LB950UE	Lite-On iHAS524	Lite-On iHAS424
Media	DVD-R	DVD-R	DVD-R
Media Write Speed:	16x	16x	16x
Avg Speed:	11.98x	12.09x	12.09x
Start Speed:	6.70x	6.78x	6.77x
End Speed:	16.01x	16.13x	16.14x
Type	CAV	CAV	CAV

Nothing out of the ordinary with the Plextor PX-LB950UE's DVD-R read speed here - 16x is spot on.
