| Processor |
| Socket A for AMD
Athlon / Duron 550MHz ~ 1.3GHz+ CPU |
| Chipset |
| VIA KT133A and VIA
V82C686B |
| FSB |
| 266/200 MHz |
| Memory |
| 3 x DIMM Socket to Support Max. 1.5GB
PC133/VC133 non-ECC SDRAM |
| Expansion Slots |
| 1 x AGP Pro / AGP 4X |
| 4 x PCI |
| 1 x PCI/AMR Shared |
| VGA |
| AGP Pro/4X Slot |
| IDE Ports |
| 2 x UltraDMA/100
(Promise ATA-100) |
| Audio (Optional) |
| AC ' 97 Compliant Codec |
| Special Features |
| Power Loss Recovery,
ASUS JumperFree, CPU Throttle, STR
(Suspend-to-RAM), SFS (Stepless Frequency Selection) |
| Back
Panel I/O Ports |
| 2 x USB Ports |
| 1 x Parallel Port (EPP, ECP), 2 x
Serial Ports |
| 1 x PS/2 Keyboard Port, 1 x PS/2
Mouse Port |
| 1 x Game/MIDI
(Optional) |
| 1 x Audio I/O
(Optional) |
| Onboard I/O Interface |
| One Header Supports Additional 2 USB
Ports |
| 20-pin ASUS
Panel |
| SIR (Integrated Serial
Infrared) |
| Headphone |
| MIC |
| CD/AUX/Modem Audio In |
| CPU/Power Supply/Chassis
Fan |
| ATX Power |
| IDE LED |
| BIOS |
| 2Mb Award BIOS, PnP,
ACPI, SMBIOS 2.3, Trend ChipAway Virus (TCAV), Green, Boot
Block BIOS |
| Industrial Standard |
| PCI v2.2 and USB v1.1 |
| Manageability |
| WfM 2.0, DMI 2.0, WOL, WOR, Chassis
Intrusion, SMBus |
| Package Contents |
| User's Manual |
| UltraDMA/100 Cable x 1 |
| IDE Cable x 1 |
| Floppy Cable x 1 |
| 2-Ports USB Bracket x 1 |
| Support CD |
| Board Size |
| ATX Form Factor: 9.6" x 12.0"
(24.5cm x 30.5cm) |
