Mushkin HP3-10666 2GB DDR3-1333 Memory Kit Review
Mushkin HP3-10666 2GB DDR3-1333 Memory Kit Review - PCSTATS
The Mushkin memory that's up for testing today is its 2GB HP3-10666 (DDR3-1333) memory kit. By default the memory is rated to run at 1333 MHz with low CAS latency timings of 6-7-6-18, on a voltage of 1.7-1.8V.
 86% Rating:
Filed under: Memory Published:  Author:
External Mfg. Website: Mushkin Oct 24 2007   Max Page
Home > Reviews > Memory > Mushkin HP3-10666

How does the tight timing DDR3 overclock?

Overclocking Results:
6-7-6-18 8-8-8-20
memory speed:

1452 MHz

1760 MHz

If you're new to Overclocking and not sure what to do, check out these two excellent Guides for some pointers:
Overclocking the CPU and Memory
Overclocking the Videocard

When it comes to memory testing, PCSTATS has a lot of experience under our belt to rely on... yet while we've tested a handful of DDR3 memory modules I think we're still a little green on DDR3's full capability. This will be the first time we're overclocking DDR3 memory modules with tight timings, so it's uncharted waters for the Mushkin HP3-10666 RAM.

Each 1GB stick of Mushkin HP3-10666 was installed into an Asus BLITZ Extreme motherboard, along with an Intel Core 2 Duo E6750 processor. Before the overclocking began, the CPU clock multiplier was set to 6x so the processor would not limit the memory.

Starting at 333 MHz, the Mushkin HP3-10666 memory speed was increased in 5 MHz increments. Early on it was clear that these DDR3-1333 modules wouldn't get very far tight 6-7-6-18 timings. The ASUS Blitz Extreme motherboard had just reached 350 MHz FSB (1400MHz memory speed) when the system started to show signs of instability, which demanded an increase in memory voltage to 1.9V.

The Mushkin HP3-10666 memory didn't overclock any further with its tight timings, and in the end reached a maximum speed of 363 MHz FSB, or 1452 MHz memory frequency.

Pushing the Mushkin HP3-10666 memory harder, either by raising the voltage or speed, didn't help.

Let's loosen the memory timings and see how the Mushkin memory handles overclocking with lax timings.

Starting from the 363 MHz point, with timings loosened to 8-8-8-24, we began overclocking the Mushkin HP3-10666 again.

The Mushkin memory handled the speed increases much better this time around, reaching a maximum speed of 1760 MHz with 2.0V. It's not the best overclock we've seen from the small collection of DDR3 memory PCSTATS has tested thus far, but it's not bad either. The Mushkin HP3-10666 is for low latency memory users, not those who want really high speeds.

You'll see in the benchmarks shortly what latency does for performance. Any guesses?

Prelude to Benchmarks

The details of how the Mushkin HP3-10666 DDR3 memory test system was configured for benchmarking, including the specific hardware, software drivers, operating system and benchmark versions are indicated below. In the second column are the general specs for the reference platforms this 2GB pair of HP3-10666 DDR3 memory is to be compared against. Please take a moment to look over PCSTATS test system configurations before moving on to the individual benchmark results.

DDR3 Test Methodology

On Intel Socket 775 Core 2 Duo test systems, we're only interested in seeing how high we can go with the DDR3 memory running 1:2, as running with other dividers puts the overclocking bottleneck elsewhere and not with the system memory. The DDR3 RAM latency must run at its lowest possible setting, as quick access is more important to the CPU design. Just for arguments sake, we will also be conducting overclocking tests to see how high the memory will go with lax timings (8-8-8-24), although we will only benchmark the system with the tight memory timings.

PCSTATS Test System Configurations
test system

intel Core 2 Duo E6750

Clock Speed:

8 x 333 MHz = 2.66 GHz


Asus BLITZ EXTREME (Intel P35 Express / DDR3)



Memory: 2GB Kit Corsair DOMINATOR Twin3X2048-1800C7D (DDR3)
2GB Kit Super Talent W1866UX2G8 (DDR3)
2GB Kit Crucial Ballistix PC3-12800 (DDR3)
2GB Kit Mushkin HP-10666 (DDR3)
Hard Drive: 74GB Western Digital Raptor WD740
CDROM: AOpen Combo 52x
PowerSupply: PC Power & Cooling TurboCool 510 SLI
Heatsink: Intel Reference
Software Setup:

Microsoft Windows Vista Ultimate
Intel INF
nVIDIA Forceware 162.22


SiSoft Sandra XI
Doom 3
Call of Juarez
Lost Planet
