ASUS EAH4550 Radeon HD 4550 Half-Height Videocard Review
ASUS EAH4550 Radeon HD 4550 Half-Height Videocard Review - PCSTATS
Abstract: Today PCSTATS is testing ATI's latest entry-level videocard for budget PC builders and home theatre enthusiasts; the leaner, lighter, and less expensive RV710 GPU at the heart of the Radeon HD 4550 video card.
 75% Rating:
Filed under: Video Cards Published:  Author:
External Mfg. Website: ASUS Mar 09 2009   Max Page
Home > Reviews > Video Cards > ASUS EAH4550

Videocard Benchmarks: Crysis, FEAR AA/AF

Crysis 1.2

Source: Electronic Arts

Crysis is a science fiction first-person shooter developed by Crytek. Crysis uses Microsoft's new API, DirectX 10 for graphics rendering, and includes the new engine—the CryEngine 2—that is the successor to Far Cry's CryEngine. CryEngine 2 is among the first engines to use the DirectX 10 framework of Windows Vista, but can also run using DirectX 9, both on Vista and Windows XP.

PCSTATS Benchmark ReportCrysis 1.2 (no AA) - DirectX10
1280x1024 HQ Points Ranking
Palit HD4870 X2 2GB 40.46
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A 39.7
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A (Crossfire) 39.105
MSI R3870X2-T2D1G-OC 39.4
ASUS EAH4850 HTDI/512M 40.835
MSI R4830-T2D512-OC (Radeon 4830) 36.55
ASUS EAH4550 512M 9.77
1600x1200 HQ Points Ranking
Palit HD4870 X2 2GB 38.2
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A 34.2
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A (Crossfire) 37.17
MSI R3870X2-T2D1G-OC 33.8
ASUS EAH4850 HTDI/512M 30.79
MSI R4830-T2D512-OC (Radeon 4830) 27.46
ASUS EAH4550 512M 7.05
1920x1200 HQ Points Ranking
Palit HD4870 X2 2GB 35
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A 29.9
ASUS EAH3870 X2 1GB TOP/G/3DHTI/1G/A (Crossfire) 34.07
MSI R3870X2-T2D1G-OC 29.7
ASUS EAH4850 HTDI/512M 26.2
MSI R4830-T2D512-OC (Radeon 4830) 23.43
ASUS EAH4550 512M 6.38

Crysis is a beauty at crushing videocard hopes and dreams, and the ASUS Radeon EAH4550 fairs no better than 9.77FPS at 1280 with High Quality effects enabled. As the Radeon 4550 is the only entry-level videocard PCSTATS has tested in Crysis we can't say how well it compares to the Geforce 8600GTS, or Radeon Hd 3650.

Sierra FEAR 1.08 - AA/AF Tests

Source: Sierra

FEAR is Sierra's latest first person shooter which relies heavily on DirectX 9 features. With its "Soft Shadows" feature enabled, even the fastest video cards run at a crawl.

PCSTATS Benchmark ReportSierra FEAR SS Disabled 1600x1200 - AA/AF Tests
4x AA / 4x AF Points Ranking
Palit HD4870 X2 2GB 203
Asus EAH3870 X2 1GB TOP/G/3DHTI/1G/A 117
MSI R3870X2-T2D1G-OC 110
Diamond Viper Radeon HD 2900XT 81
Asus EAH4850 HTDI/512M 77
MSI R4830-T2D512-OC (Radeon 4830) 83
ASUS EAH4550 512M 17
Diamond HD 3650 PE 512 12
nVidia Geforce 9600GTs in SLI 133
Asus EN9600GT Top/HTDI/512M 71
Foxconn 9600GT-512NOC 76
Palit Geforce 9600GT 512 77
Biostar V903GT52-NV1AN 71
MSI NX8800GTX-T2D768E 79
Foxconn FV-N88SMCD2-ONOC 48
MSI NX8800GTS-T2D320E-HD-OC 45
Palit 8800GT Super+ 1GB 74
MSI NX8800GT-T2D512E-OC 72
Foxconn 8600GTS-256 24
MSI NX8600GTS-T2D256E-OC 25
Biostar Sigma-Gate GeForce 7600GS 38
8xQ AA / 8x AF Points Ranking
Palit HD4870 X2 2GB 144
Asus EAH3870 X2 1GB TOP/G/3DHTI/1G/A 68
Asus EAH3870 X2 1GB TOP/G/3DHTI/1G/A (Crossfire) 125
MSI R3870X2-T2D1G-OC 39
Diamond Viper Radeon HD 2900XT 59
Asus EAH4850 HTDI/512M 52
MSI R4830-T2D512-OC (Radeon 4830) 56
ASUS EAH4550 512M 17
Diamond HD 3650 PE 512 8
nVidia Geforce 9600GTs in SLI 82
Asus EN9600GT Top/HTDI/512M 43
Foxconn 9600GT-512NOC 46
Palit Geforce 9600GT 512 46
Biostar V903GT52-NV1AN 42

Like many entry-level videocards, the ASUS Radeon EAH4550 simply can't run FEAR with anti-aliasing turned on and get acceptable frame rates - the best it manages is 17FPS.With all the benchmarks done, it's time to take a final look at the ASUS EAH4550 videocard...

An entry level videocard for your HDMI needs?

The ASUS EAH4550 entry-level videocard makes a strong case for itself as an affordable way to easily bring HDMI into an existing HTPC or budget office system. It also fills a role in older PCs that may now require a graphics card that's a little stronger than the integrated graphics originally supplied on the motherboard.

The ASUS EAH4550 videocard is priced at $70 CDN ($50 USD, £35 GBP) and includes a half-height IO bracket with dedicated HDMI jack that outputs audio. In the benchmarks it did manage good results for its entry-level class, outperforming the Radeon 3650 by a small margin. With that said, playing the latest 3D games at high resolutions was never the point of this videocard, and it still fares well for 2D gaming or lightweight gaming in titles that are a few years old or with detail settings on low or medium quality.

While gamers will want to opt for something that's a little more powerful, PCSTATS found that the ASUS EAH4550 was more than powerful enough to playback High Definition 1920 x 1080 content, and AMD has done a great job of having this card take the task of decoding HD off of the CPU's workload and letting the RV710 GPU handle it. Plugging it into an 1080p-capable, audio-equipped monitor like the ASUS VH242H via HDMI was effortless and neither sound or picture quality had any signs of distortion or artifacting. Total system power draw with this graphics card was idle 76W, peak 111W.

Those that have been looking for a good low-profile half-height videocard for small form factor and HTPC cases will find that the ASUS EAH4550's features handle pretty much all of your media playback needs. The EAH 4550 offers a compact package that runs cool, quiet and is dirt cheap. Throw in hassle free HDMI output and this AMD Radeon videocard could be the perfect complement for a computer that will be playing HD content.

PCSTATS Best Value Award

Find out about this and many other reviews by joining the Weekly PCstats.com Newsletter today! Catch all of PCSTATS latest reviews right here.
